The PMC8 SUB can be used as a compact stand-alone subwoofer within conventional multichannel systems, or as an XBD cabinet, creating a full-range PMC6 XBD...

Vendor :PMC

Type :Studio Subwoofer

R47,999.00

Add to wishlist

The PMC8 SUB can be used as a compact stand-alone subwoofer within conventional multichannel systems, or as an XBD cabinet, creating a full-range PMC6 XBD midfield monitor. When used in this way, the dedicated ‘XBD’ DSP mode marries the speakers and sub unit together, creating a coherent full-range system. Our subs are also perfectly suited to use in multi-channel and immersive systems, as our ATL™ bass-loading technology provides a gentler low-order LF roll-off than conventional ported cabinets, allowing a smoother, seamless integration between the height and surround channels and the sub.



Featuring one custom eight-inch long-throw bass-driver, the PMC8 SUB is powered by a single 300W Class-D amplifier and controlled by the same powerful DSP engine as our other active models. DSP facilities include sophisticated room boundary equalisation options, parametric EQ, time delay, phase inversion, and the unique XBD mode, all configured via the loudspeaker’s rear panel or the browser-based SoundAlign™ software.

SOUNDALIGN™ Smart & Network Equipped

The SoundAlign™ web interface gives you an unique and responsive way of controlling and configuring your near-field and mid-field active monitors and their subs. The SoundAlign™ allows you to run large multichannel systems smoother with smart features such as:

Group Filters
Easily manage many speakers

Monitor Selector
View your system and select monitors to adjust

Speaker Controls
Modify any speaker parameter – Level, EQ & more

Settings
Manage presets & update firmware
Main features:

  • Active subwoofer with an 8-inch bass driver and ATL™ bass loading
  • Frequency response: 25Hz - 500Hz (- 3dB) (@1m full space, on-axis)
  • Max. cont. SPL: 109dB @1m (quarter space value calculated as +3dB from half space measurement.
  • Unweighted input,20-20kHz Pink Noise (IEC) with 12dB CF for 2 hours AES2-1984 duration)
  • State-of-the-art Class-D amplifier: 300W
  • Analogue/AES3 digital input (16/24-bit, 18 -192kHz sample rate)
  • Digital ‘through’ output (AES3 24-bit 96kHz)
  • SoundAlign™ network control interface for single or group EQ & settings
  • Sophisticated DSP driver protection, EQ, and delay/phase options
  • Dedicated XBD configuration mode

  • Tech Specs:

    • Type: Studio subwoofer
    • Powered: Yes
    • Power Configuration: 8-inch bass driver and ATL™ bass loading
    • LF Driver Size: 8" Woofer
    • Effective ATL™ Length: 3m (9.8ft)
    • Frequency Response: 25Hz - 500Hz (- 3dB) (@1m full space, on-axis)
    • Sensitivity: +4dBu input signal = 98dB SPL @ 1m
    • Max continuous SPL: 109dB @1m
    • Max Peak SPL: 121dB @1m
    • Input Types: XLR switchable between analogue & digital AES3
    • Output Types: XLR digital AES3 (fixed 24-bit @ 96kHz)
    • Network: Ethernet with PMC SoundAlign web interface
    • Latency: 2.4mS
    • Amplifier power: 300W
    • Idle Power: 50W
    • Max Power: 1500W
    • Mains: 100 - 240VAC auto-switching, 50-60Hz
    • Cabinet dimensions: H 266mm (10.5”) | 551mm (21.7”) | D 440mm (17.3”)
    • Weight: 18.5kg (40.8lbs) each
