WesAudio Due-Pre 500 Series Preamp

WesAudio Due-Pre 500 Series Preamp

WesAudio Due-Pre A discrete mic/instrument preamp designed into a 500 series unit. This preamp has two modes of operation, the first being a classic British...

Vendor :WesAudio

Type :Microphone Preamplifier

R13,399.00

Add to wishlist

WesAudio Due-Pre

A discrete mic/instrument preamp designed into a 500 series unit. This preamp has two modes of operation, the first being a classic British styled preamp (Red) and a vintage American styled preamp (Green), each of these preamp modes have different great sounding sonic textures both being known for their classic sound by many professionals. This preamp features two pads one on the input (20dB) and another one on the output (8dB) to allow you to saturate both preamp and output transformers.

Additionally DUE-PRE has front input XLR Combo socket which can be used in both ways: as a mic input and as a instrumental input. Instrumental input is a high impedance input of which signal feeds input transformer through FET transistor. Module can draw up to 5 W of power.

Main features:

  • High quality Grayhill gain switch
  • 64dB of gain (preamps are matched with 0.5dB accuracy)
  • Canrhill in/out transformers
  • 20dB input PAD
  • 8dB output PAD (allowing saturation of both preamp and transformer)
  • Polarity Reverse switch
  • Front auto-sense XLR mic
  • Hiz Fet DI front input (the signal passes through the input transformer)
  • LED VU meter

  • Tech Specs:

    • Preamp Type: Solid State
    • Number of Channels: 1
    • Chassis:  Module
    • Phantom Power: Yes +48
    • Analog Inputs: 1 x 1/4"
    • Input impedance: 1200ohm
    • Output Impedance: 600ohm
    • Power Consumption: Up to 5w

    Also see the WesAudio TITAN Chassis to integrate and connect 500 Series analogue equipment with the convenience of 10 powered slots.

    WesAudio TITAN NG500 Recall Chassis.
