Violectric DHA V226 Headphone Amplifier DAC and Pre-amp - Special Order
Tax included.
Description
Perfect for Planar Magnetic Headphones
Introducing the DHA V226 DAC (digital to analogue converter) balanced headphone amplifier with pre-amp. Violectric is a brand of Lake People, a famous German recording and listening equipment manufacturer with a respected reputation in the recording production industry.
The DHA V226 sports powerful DAC hardware with its Cirrus-based CS43131 DAC chip which supports 32-bit PCM decoding and an impressive 130 dB dynamic range. Through USB-C, sample rates as high as 384 kHz PCM and up to 256 DSD.
The success of the Violectric DHA V226 headphone amplifier circuitry can be found in its praised and award-winning predecessors V200, V280 and V281. Inside the DHA V226 you can enjoy similar features of natural but smooth and exceptional sound.
Overview
Because of its matchless technology the DHA V226 not only offers a powerful headphone amplifier with DAC and pre-amp, but also:
Lowest noise - only a very small amount of internal gain. This makes the amplifier's self-generated noise inaudible.
High output voltage - due to 50-volt internal operating voltage. Therefore ideally suited for high-impedance headphones deserving high output voltage swing.
High output power - thanks to the power of this amplifier not even the most demanding headphones would need more. Making the DHA V226 best suited for headphones with low impedances as well as magnetostatic headphones!!
High damping factor - due to the lowest output impedance. Therefore the ideal match for difficult-to-drive headphones without negative side effects and with the guarantee for any uncompromising frequency response.
Functions:
The headphone outputs or the rear line outputs can be activated/deactivated by a switch on the front. Connect not only your headphones to the DHA V226 but also your power amplifier or your active speakers and enjoy a compact and fantastic sounding headphone amplifier with topnotch DAC and a first-class preamplifier
Main features:
Tech Specs:
- Type: Headphone Amp
- Form Factor: Desktop
- Stereo Inputs: 2x RCA (unbalanced)
- Stereo Outputs: 1x 6.3mm jack (unbalanced), 1x 4.4mm Pentaconn (symmetrical), 1x XLR (balanced), 1x RCA (unbalanced)
- USB: 1x USB-C
- Sample rate: 384 kHz / 32-Bit (PCM)
- Max. input voltage: + 21 dBu
- Frequency range: 5 Hz ... 250 kHz (- 0,5 dB)
- Headphone Output Power: 1500 mW @ 16 Ohms, 2200 mW @ 32 Ohms, 2800 mW @ 50 Ohms, 3500 mW @ 100 Ohms, 1800 mW @ 300 Ohms, 900 mW @ 600 Ohms
- Input impedance: 10k Ohms
- Output impedance: < 1 Ohm
- Dynamic range: >131 dB (A-wtd)
- Noise: <-102 dBu (A-wtd)
- Crosstalk: -100 dB (1 kHz) / -95 dB (15 kHz)
-
Power Supply: Internal 230 V / 115 V AC
- Height: 65 mm
- Width: 170 mm
- Depth: 252 mm
- Weight: 3 kg
- Discover more Violectric [DHA V226]: https://www.violectric.de/en/products/headphone-preamps/violectric-dha-v226
But If you want to confirm availability first or inquire for possible discounts send us a quick mail or open the chat tab.
