Solid State Logic SiX Channel 500 Series Channel Strip - Waiting for stock

Solid State Logic SiX Channel 500 Series Channel Strip - Waiting for stock

A deceptively simply, extremely effective SSL Mic Pre 500 Series Channel Strip with Mic/Line/Instrument Preamp, EQ, and Compressor SiX Channel Strip (SiX CH) is a...

Vendor :Solid State Logic

Type :500 Series

R8,499.00

Add to wishlist

A deceptively simply, extremely effective SSL Mic Pre

500 Series Channel Strip with Mic/Line/Instrument Preamp, EQ, and Compressor

SiX Channel Strip (SiX CH) is a single-width 500 Series channel strip using the SuperAnalogueTM channel processing features from SSL’s SiX console including the Mic-pre, low and high frequency EQ, as well as the single knob compressor.

SuperAnalogue

Using the same technology as SiX and large-format SSL consoles, SiX CH features a SuperAnalogueTM mic pre, offering wide gain range and ultra-low noise. It’s clean, fast and punchy - the perfect preamplifier for any source material.

SSL HF and LF EQ

SiX CH EQ is a classic SSL style gentle, broad stroke two-band design with high and low shelving filters at 3.5 kHz and 60 Hz, +/-15 dB gain range. Each band can be independently switched between shelving and bell curves. The bell curves change centre frequency to operate at 5 kHz and 200 Hz giving greater versatility from the two controls.

Channel compressor

A ‘one knob’ channel compressor with features that give powerful and versatile performance from its deceptively simple controls. Using the tried and tested SSL feed-forward circuit design, program-dependant attack time and automatic make-up gain to maintain signal level.

TRS Line Input

The front facing TRS line input offers a convenient way to add instruments on the fly or use SiX CH as a feature packed summing module. 10 kΩ nominal Line Input impedance can be changed to 1 MΩ via the Hi-Z switch. The 1MΩ impedance makes this input suitable for very high impedance sources such as passive guitar pickups without the need for an external DI box.

Key features

  • Equipped with channel processing features found on the renowned SSL SiX Console
  • Clean and punchy SuperAnalogue mic/line/instrument preamp
  • Classic SSL-style high shelving (3.5kHz) and low shelving (60kHz) filters;
  • frequency centers shift to 5kHz and 200Hz in bell mode
  • Surprisingly versatile 1-knob channel compressor with variable threshold and automatic make-up gain
  • 48V phantom power, 12dB/Oct 75Hz highpass filter, and polarity switch
  • Colorful 5-segment LED output signal meter
  • Requires compatible 500 Series chassis
  •

    Tech Specs

    Module signal: Mono

    Pre-Amp Gain: Variable from +6 to +72 dB (Mic), -3 to +63dB (Line)

    Mic Pre EIN: Typically 129dB

    THD+N: <0.0015%

    CMRR: >80dB (Mic), >70dB (Line)
