RODE RODELink TX-XLR Wireless Transmitter

 Pro Wireless Production Management

The TX-XLR from Rode is a wireless XLR transmitter for the RodeLink digital wireless system (available separately). It can be used to provide one-touch sync with your wireless system, is capable of supplying 48V of phantom power for microphones through its XLR input, and plug-in power through its TRS input.

Tip-top Power Management

The TX-XLR features an OLED panel, as well as an XLR input with a locking collar and a 3.5 mm TRS locking input jack. This allows you to use various input configurations; though the TX-XLR can switch between its XLR and TRS inputs, you cannot use both at the same time. Whichever input you choose, you can power the unit with two AA batteries, a Sony NP-F battery, or even continuously via a micro-USB connection. While the unit will run up 7 hours, please note that activating phantom power will reduce the usable running time, depending on the power source you're using.

Main features:

Tech Specs:

• Power source: 2 X AA Battery, NP-F Series Battery Or MicroUSB
• Antenna: Internal
• Input connection; XLR With Locking Collar, 3.5mm TRS Locking Jack Socket
• Input impedance: 1kΩ (XLR), 10kΩ (3.5mm)
• Dimensions: 120mm X 45mm X 45mm
• Weight: 222gm
