Radial Engineering ProDI 1-channel Passive Direct Box

Name: Radial Engineering ProDI 1-channel Passive Direct Box
Brand: Radial
SKU: AS_RadialProDI
Price: 3120.00 ZAR
Availability: InStock

R3,120.00

Tax included.

Description

World-class Passive DI BOX

The ProDI is a passive direct box designed for use on stage or in-home recording studios, with the ability to handle high-output instruments without distortion and a transformer-isolated output to eliminate noise from ground loops.

The heart of the ProDI is a custom wound Radial transformer. It features an exceptionally high 140kΩ input impedance to reduce loading while enabling the ProDI to handle extreme signal levels at all frequencies without distortion. This is further improved upon with an internal MuMETAL® shield to protect against electromagnetic fields that can cause unshielded transformers to distort.

Main features:

Full-range, passive direct box

Isolation transformer eliminates noise

Very low harmonic and phase distortion

Compact and rugged design

Ideal for live sound and studio.

Isolated XLR connector eliminates chassis ground potential

Custom audio transformer on input provides 100% isolation to eliminate hum- and noise-causing ground loops, while maintaining signal integrity.

Military-spec PC board, with full surface ground plane to reduce susceptibility to RF noise

High-grade switches — long life, high cycle for reliable performance

14-gauge steel welded I-beam construction makes it virtually impossible to torque the PC board

-15dB pad reduces the level going in from loud sources that could overload the circuit and cause distortion

Book-end design creates a protective zone around the switches & connectors, indestructible 14-gauge steel construction

Full no-slip rubber bottom pad provides mechanical isolation, electrical insulation and prevents unit from sliding around

Balanced male XLR output connector, AES standard with pin-1 ground and pin-2 hot

Lift switch lifts the ground to pin-1 on both channels.

Heavy-duty baked enamel finish for excellent durability

Tech Specs:

Type: Passive DI
Channels: 1
Pads: -15dB
Ground Lift: Yes
Inputs: 1 x 1/4"
Outputs: 1 x XLR, 1 x 1/4" thru
Dimensions: 45mm x 70mm x 121mm (H x W x D)
Weight: 544 g
Discover more Radial Engineering Direct Boxes [ProD2]: https://www.radialeng.com/product/prodi
