No-compromise, full Prism Sound audio quality

Titan makes no compromises on audio quality. It is the result of years of research and development into digital audio conversion and extensive dialogue with Prism Sound's customers.

Titan has the same no-compromise analogue front and back ends as Orpheus with the same fully-balanced-throughout architecture, the same isolation barriers protecting the analogue from digital and computer interference, but with a wider range of PC interface options.

Titan draws on Prism Sound's years of experience in developing digital audio products, including its range of audio test equipment, adopted by a wide variety of clients across the audio industry from pro-audio to consumer electronics. This experience means that Titan is well-behaved both as a computer peripheral and an audio processor.

Reliability is vitally important in professional recording. Prism Sound has always made extensive use of precise software calibration techniques in its converters - pots and tweaks are always unreliable, so there are none.

The design team has gone to great lengths to minimise noise and interference, in particular hum. All of the analogue circuits have galvanic isolation, while the unit's electronically balanced I/O allows it to handle common mode interference sources as well as enabling trouble-free connection to unbalanced equipment.

It is often said that THD+N figures do not always correlate well with the perception of sound quality and this is true - partly because the traditional measures of THD+N or SINAD expressed as RMS figures are rather a broad measure. With this in mind, we have taken great care to make sure that not only is the Titan noise and distortion spectrum beyond reproach, but the RMS distortion result measures up to the state of the art.

Unsurpassed Jitter Rejection

In the 1990s Prism Sound pioneered testing of sampling and interface jitter and as a result our digital audio products deliver unsurpassed jitter rejection. Prism Sound digital audio products lock up fast and re-generate ultra-stable clock outputs. Another aspect of the traditional Prism Sound converter that is retained was the clocking - it's just as important as analogue-path considerations sound-wise. So whether it's providing a high-quality master clock for the rest of the room, or dealing with a jittery clock from outside, Titan is as rock-steady as its forbears.

Tech Specs:

AD Sections

Configuration

Electronically balanced, with fully-balanced analogue signal path

Input Sensitivity

Switchable '+4dBu' (0dBFS = +18dBu) or '-10dBV' (0dBFS = +6dBu)

Input Impedance

14.5kΩ

Unbalanced Mode

Automatic

Total harmonic distortion

-117dB (0.00014%, -0.1dBFS)

THD+N

-111dB (0.00028%, -0.1dBFS)

Dynamic Range

116dB (-60dBFS)

Gain Accuracy

±0.05dB

LF roll-off

-0.05dB at 8Hz; -3dB at <1Hz

HF roll-off

fs = 44.1kHz: -0.05dB at 21.1kHz; -3dB at 22.0kHz
fs = 48kHz: -0.05dB at 23.0kHz; -3dB at 23.9kHz
fs = 96kHz: -0.05dB at 32.0kHz; -3dB at 47.9kHz
fs = 192kHz: -0.05dB at 32.0kHz; -3dB at 78kHz

CMRR

20Hz..20kHz: >70dB

Inter-channel cross-talk

1kHz: <140dB; 20Hz..20kHz: <-120dB

Inter-channel phase

10Hz..5kHz: ±0.25°,
5kHz..20kHz: ±1.0°,
20kHz..50kHz: ±2.0°,

Overkiller

Progessive limiter, auto-aligning, selectable per channel

Impact Filter

High-pass filter, -3dB at 80Hz, 40dB/decade (selectable for channels 1-4; whether in line, mic or instrument mode)

RIAA de-emphasis filter

Response accuracy:
±0.22dB at fs=44.1kHz;
±0.14dB at fs=48kHz;
±0.015dB at other sample rates

M-S matrix

Allows direct connection of mid-side mics, or non-matrix mic-preamps (selectable for channels 1-4; whether in line or mic mode)



DA Sections

Configuration

Electronically balanced, with fully-balanced analogue signal path

Output amplitude

Switchable '+4dBu' (0dBFS = +18dBu) or '-10dBV (0dBFS = +6dBu)

Output impedance

100Ω balanced, 50Ω unbalanced

Unbalanced mode

Automatic, with bootstrapping level compensation

Total harmonic distortion

-107dB (0.00045%, -1dBFS)

THD+N

-106dB (0.00050%, -0.1dBFS)

Dynamic range

115dB (-60dBFS)

Gain accuracy

±0.05dB

LF roll-off

-0.05dB at 8Hz, -3dB at <1Hz

HF roll-off

fs = 44.1kHz: -0.05dB at 21.4kHz; -3dB at 22.0kHz
fs = 48kHz: -0.05dB at 23.2kHz; -3dB at 23.9kHz
fs = 96kHz: -0.05dB at 32.0kHz; -3dB at 47.8kHz
fs = 192kHz: -0.05dB at 32.0kHz; -3dB at 76kHz

Output balance

>50dB

Inter-channel cross-talk

1kHz: <-135dB; 20Hz..20kHz: <-120dB

Inter-channel phase

10Hz..5kHz: ±0.4°,
5kHz..20kHz: ±0.25°,
20kHz..50kHz: ±0.5°,
