Heiserman Audio Type-19 Microphone - Special Order

Tone Terrific

Introducing the Heiserman Type-19 - the ultimate in form and function; a brand new mic that captures the heart and soul of the U47 in a compact and versatile package. Type-19 is extremely durable, and capable of handling anything you can throw at it. Featuring the same HK47 capsule that’s found in the acclaimed Heiserman H47tube mic, the Type 19 packs an unbelievable amount of tone into a mic that can fit into the tightest spots.

A hand-crafted capsule.
The Type-19 mic's capsule is meticulously handcrafted by a master technician at Heiserman. Their experience and commitment to quality is evident in every aspect of the design. The HK47 capsule is made in the USA with 6-micron gold sputtered, DuPont Mylar.

Breathe life into your recordings.
The Heiserman Audio Type-19 is unlike a typical mic, with no flat frequency response. It includes a custom circuit that allows for excellent performance. Its design was shaped by audio engineer feedback, with options such as a Fig 8 pattern and high pass filter for versatility.

A microphone that makes life easier.
The Heiserman Audio Type-19 is a mic designed for engineers to easily select the right mic for recording various instruments. Handcrafted in the USA with unmatched quality, this utility mic is the new industry standard.

Main features:

• Stunning good looks with a softly glowing logo
• Switchable between Cardioid, Omni, and Fig 8 patterns
• High Pass Filter and -15 dB pad
• Designed, machined, assembled, and fully made in the USA

Tech specs:

• Type: Large diaphragm condenser
• Capsule: Heiserman HK47 Dual-backplate capsule
• Diaphragm: Dual diaphragm, 6 micron, 24k gold sputtered Mylar (PET Film)
• Analogue or Digital: Analogue
• Frequency response: 20Hz – 20kHz
• SPL: 130 dB (140 w/pad) @ < 10db THD
• Output Impedance: 42 Ohm
• Amplifier Type: Field Effect Transistor
• Polar Pattern: Bi-Directional / Figure-Eight, Cardioid, Omni-Directional
• High Pass Filter: 160 Hz
• Connector: Switchcraft XLR
• Mount: Standard 57 Mic Clip
• Dimensions (LxW): 139 x 28.5 mm
• Power Supply: +48v Phantom Power (Via XLR)
