Behringer WING 48-channel Digital Mixer (Black) - Enquire for Availability

Your Sound, Your Workflow

The Behringer WING breaks away from traditional mixer design by centring its workflow around the concept of a “Source” rather than a fixed physical input. Whether it’s a mic preamp, AES50 stream, USB return, or Dante input, you can freely label it with a custom name, colour, and icon, then assign it to any channel on the desk. This highly flexible routing architecture eliminates the limitations of conventional patch bays - streamlining festival changeovers, multi-artist lineups, and complex studio setups with ease and efficiency.

Next-Level Workflow
The WING’s intuitive workflow centres around your creativity. With full stereo channel architecture and customizable fader layers, it adapts to your session – not the other way around. Whether you're engineering a complex live performance, multi-track recording, or a hybrid broadcast setup, the WING keeps you in total control.

Studio-Grade Sound, Live-Ready Performance
Thanks to premium MIDAS-designed preamps and ultra-low latency signal paths, the WING delivers audiophile-grade clarity across any application. A dedicated FX rack with over 40 studio-quality effects lets you shape your sound with surgical precision.

Designed for the Future
Expandable and network-ready, the WING supports AES50 digital snakes, Dante (via optional card), SD recording, and 3rd-party remote control – making it an ideal hub for modern hybrid productions. With constant firmware updates and a growing user community, the WING is engineered to evolve with you.

Main features:

• 48 Input Channels with full stereo capability (each can be mono/stereo without channel linking)
• 24 Motorised Faders arranged in three intuitive sections for workflow optimisation
• 10” Touchscreen Interface – responsive and customizable for ultra-fast navigation and control
• 40-Bit Floating-Point Processing with class-leading audio quality and headroom
• 8 Stereo FX Processors plus 16 FX slots for inserts – all with premium algorithms
• Fully Flexible Routing Matrix – route anything, anywhere with total freedom
• Midas Pro-Grade Preamps deliver warm, rich, analogue-style gain staging
• AES50 Networking with up to 144 input channels over three SuperMAC ports
• Dante, SoundGrid, and MADI Expansion Card Slots for studio and broadcast integration


Tech Specs:

• Type: Digital Mixer
• Channels: 48 Stereo (40 x channel, 8 x aux)
• Inputs - Mic Preamps: 8 x XLR-1/4" combo (mic/line)
• Phantom Power: Yes
• Outputs - Main: 8 x XLR
• Inputs - Digital: 1 x XLR (AES/EBU), 3 x EtherCON (AES50 SuperMAC), 1 x XLR (StageCONNECT)
• Outputs - Digital: 1 x XLR (AES/EBU), 3 x EtherCON (AES50 SuperMAC), 1 x XLR (StageCONNECT)
• Send/Return I/O: 8 x 1/4" TRS (aux in), 8 x 1/4" TRS (aux out)
• Busses/Groups: 8 x Stereo Matrix, 4 x Stereo Mains, 16 x Aux Stereo Bus
• Inserts: Dual Inserts per Bus, FX Insert Slot
• MIDI I/O: In/Out
• Data I/O: 2 x Ethernet (control/audio network)
• Headphones: 2 x 1/4"
• USB: 1 x Type B, 1 x Type A
• Computer Connectivity: USB 2.0, 24-bit/48kHz (48 x 48)
• Remote: 1 x 1/4" (GPIO 1-2), 1 x 1/4" (GPIO 3-4)
• I/O Expansion Slots: 1 x Expansion Port (24-bit/48kHz)
• Faders: 24 x 100mm Motorised
• A/D Resolution: Up to 24-bit/192kHz
• EQ Bands: 6-band Parametric EQ (channel), 8-band Parametric EQ (bus), Additional EQs and Configurations
• Effects: 8 x Premium FX Stereo Processors, 8 x Standard FX Stereo Processors, 5 x Variable Plug-in Slots
• Signal Processing: Full Dynamics Processing
• DAW Control: Yes (HUI, Mackie)
• Screen: 10" Capacitive Touchscreen, Adjustable Swivel
• Storage: 2 x SD Card Slot (dual 32 track max)
• Power Source: Standard IEC AC cable

• Power Source: 24W DC power supply (included)

• Dimensions (WxHxD): 201 x 870 x 575 mm
• Weight: 24 Kg
• Explore more Behringer Mixing Consoles [WING]: https://www.behringer.com/wing/wing.html
