Avid Pro Tools | MTRX Studio Interface for HD and HDX Systems
Tax included.
The Heart of Every High-End Pro Tools System
The Avid Pro Tools MTRX Studio is a next-generation audio interface designed for the modern professional studio. Combining pristine audio conversion, flexible I/O routing, and advanced monitoring control, MTRX Studio streamlines recording, mixing, and mastering workflows.
With high-quality AD/DA conversion, ultra-low latency performance, and support for up to 64 channels, MTRX Studio brings studio-grade reliability to your desktop or larger production environment. Its modular design allows seamless integration with Pro Tools Ultimate and other DAWs, making it the central hub for all your audio routing and monitoring needs.
Advanced AD/DA Conversion
MTRX Studio features studio-grade analog-to-digital and digital-to-analog conversion, delivering pristine audio with ultra-low distortion and high dynamic range. Every recording and playback retains the detail and transparency of the original source.
Flexible Routing & Monitoring
With up to 64 channels of routing, MTRX Studio acts as a central hub for your entire studio. Its integrated monitor controller lets you switch speakers, headphone mixes, and talkback seamlessly, giving you precise control over every signal path.
Ultra-Low Latency Performance
The MTRX Studio’s DSP and Ethernet connectivity ensure near-zero latency tracking and mixing. Whether recording multiple channels or using virtual instruments, you experience real-time performance with no compromise.
Modular & Expandable Design
Designed for professional workflows, MTRX Studio integrates smoothly with Pro Tools Ultimate, other MTRX units, and existing studio gear. Its modular design allows future expansion without needing to replace your core system.
Remote Control & Workflow Optimization
Using MTRX software, you can control routing, monitoring, and volume remotely from your DAW or desktop. This integration simplifies complex studio setups and enhances creative workflow efficiency.
Main features:
- Unmatched DSP acceleration – run thousands of plug-ins and virtual instruments in real time.
- Ultra-low latency monitoring – track with effects and zero compromise.
- PCIe architecture – high-bandwidth connectivity for pro studio performance.
- Scalable power – add up to 3 HDX cards per system for maximum DSP capacity.
- Seamless integration – optimised for Pro Tools Ultimate software.
- Trusted worldwide – the standard in major music, film, and broadcast facilities.
Tech Specs:
- Type: Pro Tools HD/HDX Interface
- A/D Resolution: 24-bit/192kHz
- Analogue Inputs: 2 x 1/4" (Hi-Z), 2 x XLR (mic), 2 x DB-25 (line)
- Analogue Outputs: 2 x DB-25 (line), 2 x 1/4" (monitor)
- Digital Inputs: Ethernet (Dante), Mini-DigiLink, 2 x Optical Toslink (ADAT)
- Digital Outputs: Ethernet (Dante), Mini-DigiLink, 2 x Optical Toslink (ADAT)
- Headphones: 2 x 1/4"
- Data I/O: 2 x Ethernet, 2 x Mini-DigiLink
- Rack Spaces: 1U
- Width: 19"
-
Simultaneous I/O: 64 x 64 (Dante), 16 x 16 (analogue, ADAT)
- Discover more Avid Pro Tools [MTRX Studio]: https://www.avid.com/products/pro-tools-mtrx-studio
If you would like to confirm availability first or inquire for possible price-matching send us a quick mail.
