Austrian Audio OD505 WL1 Active-dynamic Wireless Microphone Capsule

Wireless Liberty. Studio Finesse.

The Austrian Audio OD505 WL1 brings the groundbreaking performance of the award-winning OD505 active dynamic microphone to the wireless stage. Designed specifically for vocalists who require the mobility of a radio system without sacrificing the "Viennese" studio sound, this capsule is the ultimate upgrade for touring musicians, front-of-house engineers, and high-end broadcasters. By combining the soul of a condenser with the ruggedness of a dynamic, it ensures your voice cuts through the densest live mixes with absolute precision.

Active Dynamic Circuitry
The OD505 WL1 utilizes a state-of-the-art active dynamic design that requires only 5-10V from your transmitter to deliver condenser-level sensitivity. This innovative circuitry ensures your sound remains consistent and punchy, regardless of the transmitter's internal resistance or the wireless transmission path. You get the warmth and detail of a premium studio mic with the ruthless reliability needed for the most demanding tours.

Proprietary Open Acoustics Design
Unlike traditional capsules housed in restrictive enclosures, the OD505 WL1 features Austrian Audio’s Open Acoustics technology. By mounting the capsule as a free-standing unit, unwanted reflections and resonances from the housing are eliminated. This results in a pristine, natural sound that stays transparent even when a performer grips the grille directly, providing maximum feedback stability and high-fidelity signal quality.

Advanced Noise and Pop Suppression
Engineered for the chaos of the stage, the capsule incorporates a dual-capsule design where a passive, polarity-rotated lower capsule reduces handling noise by cancelling out vibrations. Combined with the proprietary 3D Pop Noise Diffuser, the OD505 WL1 effectively disperses the air pressure from plosives, ensuring your performance remains flawless and free from distracting "pops" and rumbles.

Main features:

• Active dynamic capsule delivering condenser-like sensitivity and detail
• Supercardioid polar pattern for superior off-axis rejection and feedback stability
• Seamless compatibility with Shure, Sony, and Lectrosonics wireless handheld transmitters
• Open Acoustics technology for resonance-free, natural sound reproduction
• Dual-capsule design for significant reduction in handling noise and mechanical vibrations
• Integrated 3D Pop Noise Diffuser to mitigate plosives without affecting tonal clarity
• Rugged Viennese craftsmanship designed to withstand the rigours of professional touring

Package Includes

1x OD505 WL1 Wireless Microphone Capsule
1x Protective Carrying Case
1x Quick Start Guide

Tech Specs:

• Type / Product: Active Dynamic Wireless Microphone Capsule
• Directional Characteristic: Supercardioid
• Capsule Type: Active Dynamic
• Frequency Range: 35 Hz – 16 kHz
• Sensitivity: 4.4 mV/Pa
• Max. SPL: 150 dB SPL
• Equivalent Noise Level: 26 dB SPL (A)
• Load Impedance: > 1 kΩ
• Supply Voltage: 5 – 10 V (< 1 mA)
• Interface Compatibility: Shure / Sony / Lectrosonics
• Dimensions: 92 mm x 53 mm x 53 mm
• Weight: 195 g
