Arturia AudioFuse 16Rig USB Audio Interface

Main Features:

• Comprehensive interface features an all-analog design with ESS and Cirrus Logic 24-bit AD/DA converters for consistent signal preservation and unwavering clarity
• 16-in/12-out design includes periodic, front-mounted I/O to keep essentials recording-ready without sacrificing connectivity for special instances of use
• Front-mounted combo jacks accommodate line-level, instrument, and XLR inputs that mirror channels 1 and 2
• Input for channels 3 and 4 can be accessed via 1/8-inch auxiliary stereo input at the front and managed from the panel for further stereo refinement
• 12 multimode analog outputs include 8 DC-coupled TRS outputs to control synth modules, expression devices, and more
• Outputs for channels 3 and 4 can be used for Re-amp, Altphones, and Directthru functions for immensely augmented recording and playback flexibility
• Standalone design allows you to manage audio sources, as well as Class Compliant MIDI devices through USB or 5-pin DIN for uncompromising control without the need for a computer
• 2 ADAT I/O pairs accommodate up to 16 total channels at 96kHz recording quality, with room for archive-grade 192kHz quality without using every channel
• Word Clock ensures virtually any master/slave sync configuration will keep things locked in step
• Monitor section’s speaker-icon button offers 3 assignable functions: dimming that won’t overwrite your established reference level; mono checking; and A/B stereo switching
• Included Arturia AudioFuse Control Center software provides deep control of Main and Cue Mixers, MIDI management, Routing Matrix, and preset design
• Entire interface can be controlled via MIDI, including mixer levels and routing management with a Class Compliant controller
• Routing Matrix is used for controlling any analog and digital destination across Monitor, Phones, ADAT, Main Mix, Cue Mix, and Auxiliary sends
• Included USB-A to USB-C cable, USB-C to USB-C cable, PSU, registration card, and removable rack ears guarantee compatibility with nearly any rack or desktop arrangement

Tech Specs

• Computer Connectivity:USB 2.0
• Form Factor:Rackmount
• Simultaneous I/O:16 x 12
• Number of Preamps:2 x mic/instrument
• Phantom Power:Yes
• A/D Resolution:Up to 24-bit/192kHz ; Optical (ADAT): 8 channels @ 96kHz, 16 channels @ 48kHz
• Effects:Arturia FX Plug-ins
• Analog Inputs:2 x XLR-1/4" combo (mic/line/Hi-Z), 1 x 1/8" TRS (front duplicate input ch 3,4), 16 x 1/4" (line)
• Analog Outputs:2 x 1/4" (monitor), 8 x 1/4" (DC coupled), 2 x 1/4" TRS (front duplicate output ch 3,4)
• Digital Inputs:2 x Optical Toslink (ADAT)
• Digital Outputs:2 x Optical Toslink (ADAT)
• Headphones:1 x 1/4", 1 x 1/8"
• MIDI I/O:1 x In, Dual Out/Thru (assignable), USB
• USB:1 x USB-C, 3 x Type A
• Clock I/O:2 x BNC (in, out), 1 x 1/8" (out)
• Features:Internal Main & Cue Mixers
• Software:AudioFuse Control Center, AudioFuse Creative Suite
• OS Requirements - Mac:macOS 10.13 or later
• OS Requirements - PC:Windows 10 or later
• Rack Spaces:1U, Rack Kit Included
• Power Supply:15V DC Power Supply (included)
